Key performance

94 ch
Power
🔧
1868 cc
Displacement
⚖️
330 kg
Weight
🏎️
170 km/h
Top speed
💺
668 mm
Seat height
18.9 L
Fuel capacity
💰
26 990 €
New price
Compare the Harley-Davidson Heritage Classic 114 with: Choose a motorcycle →

Technical specifications

Engine

Displacement
1868 cc
Power
94.0 ch @ 5020 tr/min (69.1 kW)
Torque
161.4 Nm @ 3000 tr/min
Engine type
Bicylindre en V à 45°, 4 temps
Cooling
DW2C5Z3XMYy30YrAir
Compression ratio
10.5:LxrrqXC1
Bore × stroke
102.d79Gl0 x 114.3 mm (4.0 x 4.5 inches)
Valves/cylinder
4
Fuel system
Injection. Electronic SequenXikE018Ntial Port Fuel Injection
Valve timing
DoublEHTiBbbg6R7OCLve Overhead Cams/Twin Cam (DOHC)
Starter
EleVjQqH3Vcr4cPh3ctric

Chassis

Frame
Double berceau tubulaire en acier
Gearbox
6-BCTHtVnjqXAY1C1speed
Final drive
Belt (final drivAqcjwZOIPWswme)
Clutch
Multi-plate with diaphragm sprinDrGX9fg in oil bath
Front suspension
Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual ratgdAFGPFHXe spring; ´beer can´ covers
Rear suspension
Hidden, free3Xt91 piston, coil-over monoshock; 56mm stroke; hydraulic preload adjustment

Brakes

Front brakes
Single disc. ASMnguB66Q4BS. 4-piston
Rear brakes
Single disc. ABS. 2-pistonIRTTdY floating.
Front tyre
130/90-B16 xGcvqNI8t1rtuo5
Front tyre pressure
2.48 bar
Rear tyre
150/80hXODkP5o-B16
Rear tyre pressure
2.76 bar

Dimensions

Seat height
668.00 mm
Wheelbase
1630.00 mm
Length
2415.00 mm
Fuel capacity
18.90 L
Weight
330.20 kg
Dry weight
316.20 kg
New price
26 990 €

Overview

The Heritage Classic tells a story all its own. Custom for some, cruiser for others, almost a tourer in the end, it is assuredly the most travel-ready of the Softail models. And not just that. On its handlebars or in the village square, it embodies and ensures an attractive power imbued with the scents of yesteryear.

For the uninhibited, there’s the Fat Bob; for her, it’s the horizon. And in its mirrors, one can guess the Hydra Glide from the mid-century. Fortunately, its technical underpinnings are much more up-to-date. Because the Heritage Classic completely revised its chassis and mechanics a few years ago.

Thus equipped with the Milwaukee-Eight to propel the crew properly. Larger, braver, more powerful, more torquey, it gives the Wisconsin eagle larger wings. Twin with 8 valves—a radical change for Harley’s finned mechanics—it claims an agility unknown in the upper rev range, without sacrificing its hammer blows down low. Enough to take even more pleasure over the kilometers on the Heritage. With this 114 cubic inch version, the temptation is great to travel many kilometers and enjoy a big breath with each acceleration. With a displacement of 1868 cm3, the Big Block M8 develops here 15.8 mkg. A generous force of torque, initially reserved for the high-end models of the Touring range.

Engine vigor; and riding bravery. It was time to move up a level for road efficiency. The frame benefits from a major overhaul to demonstrate superior efficiency. With a design requiring fewer welds and fewer parts, the carbon steel assembly gains weight and rigidity (+ 65%). A larger and more rigorous fork works in concert with a shock absorber placed between the seat and the top of the swingarm. No more duo of shocks under the engine. Like all Softail models, it announces better ground clearance and better behavior. In essence, the new generation Heritage Classic has lost 17 kilos.

This chapter of the Heritage also includes a paragraph of revised comfort with lockable, watertight rigid saddlebags and a retouched windshield, half tinted black. Nice for style but what about visibility? Let's not forget the LED headlights and the cruise control.

M.B(photos constructeur)

Standard equipment

  • Assistance au freinage : ABS de série
  • Régulateur de vitesse
  • Démarrage sans clé
  • Valises

Practical info

  • La moto est accessible aux permis : A

Indicators & positioning

Weight-to-power ratio
0.28 ch/kg
🔄
Torque / weight
0.49 Nm/kg
🔧
Volumetric power
49.6 ch/L
In category Custom / cruiser · 934-3736cc displacement (2715 motorcycles compared)
Power 93 ch Top 35%
50 ch median 82 ch 154 ch
Weight 330 kg Lighter than 31%
240 kg median 308 kg 380 kg
P/W ratio 0.28 ch/kg Top 41%
0.19 median 0.26 0.52 ch/kg
