Key performance
249 cc
Displacement
960 mm
Seat height
9.2 L
Fuel capacity
Compare the KTM 250 EXC-F with: Choose a motorcycle →
Technical specifications
Engine
- Displacement
- 249 cc
- Engine type
- Single cylinder, four-stroke
- Cooling
- Liquid
- Compression ratio
- 12.8:1
- Bore × stroke
- 76.0 x 54.8 mm (3.0 x 2.2 inches)
- Valves/cylinder
- 4
- Fuel system
- Carburettor. Keihin MX FCR 39
- Valve timing
- Double Overhead Cams/Twin Cam (DOHC)
- Lubrication
- Pressure lubrication with 2 Eaton pumps
- Ignition
- Kokusan digital
- Starter
- Kick
Chassis
- Frame
- Central double-cradle-type 25CrMo4
- Gearbox
- 6-speed
- Final drive
- Chain (final drive)
- Clutch
- Wet multi-disc clutch, operated hydraulically
- Front suspension
- WP USD Ø 48 mm (1.89
- Rear suspension
- WP monoshock PDS
- Front wheel travel
- 300 mm (11.8 inches)
- Rear wheel travel
- 335 mm (13.2 inches)
Brakes
- Front brakes
- Single disc
- Rear brakes
- Single disc
- Front tyre
- 90/90-21
- Rear tyre
- 120/90-18
Dimensions
- Seat height
- 960.00 mm
- Wheelbase
- 1475.00 mm
- Ground clearance
- 380.00 mm
- Fuel capacity
- 9.20 L
- Dry weight
- 105.70 kg
