Key performance
107 ch
Power
782 cc
Displacement
242 kg
Weight
815 mm
Seat height
20.8 L
Fuel capacity
Compare the Honda VFR800X Crossrunner with: Choose a motorcycle →
Technical specifications
Engine
- Displacement
- 782 cc
- Power
- 107.0 ch @ 10250 tr/min (78.1 kW)
- Torque
- 75.1 Nm @ 8500 tr/min
- Engine type
- V4, four-stroke
- Cooling
- Liquid
- Compression ratio
- 11.8:1
- Bore × stroke
- 72.0 x 48.0 mm (2.8 x 1.9 inches)
- Valves/cylinder
- 4
- Fuel system
- Injection. PGM-FI electronic fuel injection
- Valve timing
- Double Overhead Cams/Twin Cam (DOHC)
- Ignition
- Computer-controlled digital transistorised with electronic advance
- Starter
- Electric
Chassis
- Frame
- Diamond; aluminium twin-spar; pivotless
- Gearbox
- 6-speed
- Final drive
- Chain (final drive)
- Clutch
- Wet, multiplate with coil springs
- Front suspension
- 43mm HMAS cartridge-type telescopic fork with stepless preload and ten DF adjustment, 108mm axle travel
- Rear suspension
- Pro-Link with gas-charged HMAS damper, 7-step (stepless remote-controlled hydraulic) preload and stepless rebound damping adjustment, 120mm axle travel
- Front wheel travel
- 145 mm (5.7 inches)
- Rear wheel travel
- 148 mm (5.8 inches)
Brakes
- Front brakes
- Double disc. ABS. Floating discs. Hydraulic. Four-piston calipers.
- Rear brakes
- Single disc. ABS. Hydraulic. Two-piston calipers.
- Front tyre
- 120/70-ZR17
- Rear tyre
- 180/55-ZR17
Dimensions
- Seat height
- 815.00 mm
- Wheelbase
- 1475.00 mm
- Ground clearance
- 165.00 mm
- Length
- 2190.00 mm
- Width
- 870.00 mm
- Height
- 1360.00 mm
- Fuel capacity
- 20.80 L
- Weight
- 242.00 kg
Indicators & positioning
Weight-to-power ratio
0.44 ch/kg
Torque / weight
0.31 Nm/kg
Volumetric power
136.8 ch/L
In category Sport touring · 391-1564cc displacement (2213 motorcycles compared)
Power 107 ch Top 39%
49 ch median 100 ch 168 ch
Weight 242 kg Lighter than 45%
196 kg median 239 kg 300 kg
P/W ratio 0.44 ch/kg Top 41%
0.22 median 0.41 0.70 ch/kg
