Key performance
48 ch
Power
562 cc
Displacement
220 kg
Weight
780 mm
Seat height
15.0 L
Fuel capacity
15 599 €
New price
Compare the Yamaha TMAX Tech Max with: Choose a motorcycle →
Technical specifications
Engine
- Displacement
- 562 cc
- Power
- 47.6 ch @ 7500 tr/min (34.3 kW)
- Torque
- 55.7 Nm @ 5250 tr/min
- Engine type
- Twin, four-stroke
- Cooling
- Liquid
- Compression ratio
- 10.9:1
- Bore × stroke
- 70.0 x 73.0 mm (2.8 x 2.9 inches)
- Valves/cylinder
- 2
- Fuel system
- Injection
- Valve timing
- Double Overhead Cams/Twin Cam (DOHC)
- Lubrication
- Dry sump
- Ignition
- TCI
- Starter
- Electric
Chassis
- Frame
- Die-cast aluminium chassis
- Gearbox
- Automatic
- Final drive
- Belt (final drive)
- Front suspension
- Telescopic fork
- Rear suspension
- Swingarm
- Front wheel travel
- 120 mm (4.7 inches)
- Rear wheel travel
- 117 mm (4.6 inches)
Brakes
- Front brakes
- Double disc. 4-piston. Hydraulic. Optional ABS.
- Rear brakes
- Single disc. Hydraulic. Optional ABS.
- Front tyre
- 120/70-R15
- Rear tyre
- 160/60-R15
Dimensions
- Seat height
- 780.00 mm
- Wheelbase
- 1575.00 mm
- Ground clearance
- 135.00 mm
- Length
- 2195.00 mm
- Width
- 780.00 mm
- Height
- 1415.00 mm
- Fuel capacity
- 15.00 L
- Weight
- 220.00 kg
- New price
- 15 599 €
Standard equipment
- Régulateur de vitesse
- Poignées chauffantes
- Pare brise réglable électriquement
Practical info
- Véhicule accessible au permis A2 ou bridable à 47.5ch / 35 Kw
- La moto est accessible aux permis : A2
Indicators & positioning
Weight-to-power ratio
0.21 ch/kg
Torque / weight
0.25 Nm/kg
Volumetric power
83.5 ch/L
In category Scooter · 281-1124cc displacement (525 motorcycles compared)
Power 47 ch Top 24%
24 ch median 38 ch 66 ch
Weight 220 kg Lighter than 61%
174 kg median 222 kg 277 kg
P/W ratio 0.21 ch/kg Top 25%
0.13 median 0.20 0.25 ch/kg
