Key performance
68 ch
Power
1450 cc
Displacement
165 km/h
Top speed
640 mm
Seat height
18.5 L
Fuel capacity
Compare the Harley-Davidson Dyna Low Rider with: Choose a motorcycle →
Technical specifications
Engine
- Displacement
- 1450 cc
- Power
- 68.0 ch @ 5400 tr/min (49.6 kW)
- Engine type
- V2, four-stroke
- Cooling
- Air
- Compression ratio
- 9.6:1
- Bore × stroke
- 95.3 x 101.6 mm (3.8 x 4.0 inches)
- Valves/cylinder
- 2
- Fuel system
- Injection. Electronic Sequential Port Fuel Injection (ESPFI)
- Valve timing
- Overhead Valves (OHV)
- Lubrication
- Dry sump, internally mounted, crank driven gerotor pressure and dual scavenge pump with spin oil filter
- Ignition
- Single-fire, non-wasted, map-controlled spark ignition
- Starter
- Electric
Chassis
- Frame
- Mild steel, tubular frame; rectangular section backbone; stamped, cast and forged junctions, forged fender supports; MIG welded
- Gearbox
- 5-speed
- Final drive
- Belt (final drive)
- Front suspension
- 39 mm with polished aluminum fork triple clamp and dual-rate springs
- Rear suspension
- Coil over dual shock
Brakes
- Front brakes
- Double disc. Four-piston calipers.
- Rear brakes
- Single disc. Floating disc. Two-piston calipers.
- Front tyre
- 100/90-H19
- Rear tyre
- 160/70-V17
Dimensions
- Seat height
- 640.00 mm
- Wheelbase
- 1664.00 mm
- Ground clearance
- 142.00 mm
- Length
- 2364.00 mm
- Fuel capacity
- 18.50 L
- Dry weight
- 279.00 kg
Indicators & positioning
Volumetric power
46.9 ch/L
In category Custom / cruiser · 725-2900cc displacement (3440 motorcycles compared)
Power 68 ch Top 57%
46 ch median 74 ch 140 ch
