Key performance
78 ch
Power
1690 cc
Displacement
321 kg
Weight
170 km/h
Top speed
650 mm
Seat height
18.9 L
Fuel capacity
19 750 €
New price
Compare the Harley-Davidson 1690 SOFTAIL SLIM FLS with: Choose a motorcycle →
Technical specifications
Engine
- Displacement
- 1690 cc
- Power
- 78.0 ch @ 5250 tr/min (57.4 kW)
- Torque
- 131.4 Nm @ 3250 tr/min
- Engine type
- Bicylindre en V à 45°, 4 temps
- Cooling
- par air
- Compression ratio
- 9.6 : 1
- Bore × stroke
- 98.4 x 111.1 mm
- Valves/cylinder
- 2
- Camshafts
- 2 ACT
- Fuel system
- Injection
Chassis
- Frame
- tubulaire en acier, poutre principale rectangulaire
- Gearbox
- boîte à 6 rapports
- Final drive
- Courroie
- Front suspension
- fourche téléscopique Ø 41.3 mm, déb : 130 mm
- Rear suspension
- Monoamortisseur horizontal masqué, déb : 86 mm
Brakes
- Front brakes
- Freinage 1 disque Ø 300 mm, étrier 4 pistons
- Rear brakes
- Freinage 1 disque Ø 292 mm, étrier 2 pistons
- Front tyre pressure
- 2.48 bar
- Rear tyre pressure
- 2.76 bar
Dimensions
- Seat height
- 650.00 mm
- Fuel capacity
- 18.90 L
- Weight
- 321.00 kg
- Dry weight
- 308.00 kg
- New price
- 19 750 €
Standard equipment
- Assistance au freinage : ABS en option
Practical info
- Véhicule accessible au permis A2 ou bridable à 47.5ch / 35 Kw
- La moto est accessible aux permis : A, A2
Indicators & positioning
Weight-to-power ratio
0.24 ch/kg
Torque / weight
0.41 Nm/kg
Volumetric power
45.5 ch/L
In category Custom / cruiser · 845-3380cc displacement (3005 motorcycles compared)
Power 77 ch Top 49%
49 ch median 77 ch 148 ch
Weight 321 kg Lighter than 35%
235 kg median 305 kg 379 kg
P/W ratio 0.24 ch/kg Top 61%
0.18 median 0.25 0.49 ch/kg
