Key performance
48 ch
Power
500 cc
Displacement
235 kg
Weight
165 km/h
Top speed
835 mm
Seat height
20.0 L
Fuel capacity
5 990 €
New price
Compare the Benelli TRK 502 with: Choose a motorcycle →
Technical specifications
Engine
- Displacement
- 500 cc
- Power
- 47.6 ch @ 8500 tr/min (35.0 kW)
- Torque
- 46.0 Nm @ 6000 tr/min
- Engine type
- Bicylindre en ligne, 4 temps, calé à 180°
- Cooling
- Liquid
- Compression ratio
- 11.5:1
- Bore × stroke
- 69.0 x 66.8 mm (2.7 x 2.6 inches)
- Valves/cylinder
- 4
- Camshafts
- 2 ACT
- Fuel system
- Injection. EFI
- Valve timing
- Double Overhead Cams/Twin Cam (DOHC)
- Lubrication
- Pressure splash l
- Ignition
- T.C.I
- Starter
- Electric
- Euro standard
- Euro 5
Chassis
- Frame
- Steel trellis
- Gearbox
- 6-speed
- Final drive
- Chain (final drive)
- Clutch
- Wet multi-plate
- Front suspension
- Adjustable Upside-down forks 50mm
- Rear suspension
- Mono-shock-absorber
- Front wheel travel
- 140 mm (5.5 inches)
- Rear wheel travel
- 45 mm (1.8 inches)
Brakes
- Front brakes
- Double disc. 4-piston, ABS
- Rear brakes
- Single disc. Single piston calliper, ABS
- Front tyre
- 120/70-ZR17
- Rear tyre
- 160/60-ZR17
Dimensions
- Seat height
- 835.00 mm
- Seat type
- Selle biplaces
- Wheelbase
- 1505.00 mm
- Ground clearance
- 190.00 mm
- Length
- 2200.00 mm
- Width
- 915.00 mm
- Height
- 1450.00 mm
- Fuel capacity
- 20.00 L
- Weight
- 235.00 kg
- Dry weight
- 210.00 kg
- New price
- 5 990 €
Standard equipment
- Assistance au freinage : ABS
- Taille de l'écran TFT couleur : 12,70 cm / 5 pouces
- Indicateur de vitesse engagée
- Bluetooth
- Prise USB
- Commodes rétro-éclairés
Practical info
- Véhicule accessible au permis A2 ou bridable à 47.5ch / 35 Kw
- La moto est accessible aux permis : A, A2
Indicators & positioning
Weight-to-power ratio
0.20 ch/kg
Torque / weight
0.20 Nm/kg
Volumetric power
93.8 ch/L
In category Enduro / offroad · 250-1000cc displacement (1531 motorcycles compared)
Power 47 ch Top 55%
23 ch median 48 ch 97 ch
Weight 235 kg Lighter than 7%
108 kg median 166 kg 237 kg
P/W ratio 0.20 ch/kg Top 75%
0.14 median 0.26 0.44 ch/kg
